PLD1000 Series Centrifuge - Top Performance & Appearance
Product features
The PLD1000 Series Centrifuge is a top-performing benchtop plate centrifuge designed for solid-liquid separation in industries such as pharmacy, food, and chemistry. Featuring a unique bag-pulling method, this centrifuge ensures complete discharging and filter cloth regeneration, enhancing efficiency. With optional configurations for safety protection, motor drive, and feed type, this centrifuge offers a customizable solution for various separation needs.
Team strength
The PLD1000 Series Centrifuge is a top-of-the-line product designed to showcase both impressive performance and stunning appearance. This centrifuge is the result of a dynamic team of experts who have combined their skills and knowledge to create a high-quality and visually appealing device. The team's strength lies in their ability to collaborate effectively, utilizing their individual strengths to achieve a common goal of producing a centrifuge that delivers top performance while also looking sleek and modern. With a focus on innovation and attention to detail, this team has created a centrifuge that stands out in both functionality and design.
Enterprise core strength
The PLD1000 Series Centrifuge combines top performance and stunning appearance to deliver exceptional results in a laboratory setting. This powerful centrifuge is a testament to team strength, as it is designed with precision engineering and innovative technology to meet the needs of professional researchers and scientists. The team behind the PLD1000 Series Centrifuge has worked tirelessly to ensure that every detail, from its sleek design to its high-speed capabilities, reflects their commitment to excellence. With this centrifuge, customers can trust in the expertise and dedication of a team that values quality, reliability, and cutting-edge performance.
Product Description
OPERATING PRINCIPL
* Removing the residual solid cake by bag - pulling method. Eliminate all solid cakes left over the process of scraper
discharging through reciprocal movement of the pneumatic pulling bag device, to realize complete discharging and filtering cloth regeneration.
* External cylinder+rod drive design, reliable in work
* Fully-enclosed discharge hopper design separating the material from the driving components of the centrifuge.
Feed type: Inclined feed disk, side feed pipe, middle feed pipe and material level detection device
Scraper discharge: Pneumatic, hydraulic and liquid-phase skimming disc
Motor drive: Common motor, inverter-duty motor and explosion- proof motor
Safety protection: Nitrogen protection (anti-explosion) system, vibration protection, temperature protection, electric-mechanical interlocking, speed monitoring and overload protection.
CIP system: Cleaning ball and spray pipe
Washing mode: Atomized nozzle rinsing, feed disk washing, pulse type washing
Nitrogen protection system: Automatic control device, hydraulic sealing device and gas -liquid separator.
Product parameters
Items | Model | ||||||||
PLD1000 | PLD1250 | PLD1400 | PLD1600 | PLD1800 | |||||
Basket Dia(mm) | 1000 | 1250 | 1400 | 1600 | 1800 | ||||
Basket Volume(L) | 180 | 400 | 600 | 800 | 1250 | ||||
Max. load(kg) | 230 | 500 | 700 | 1000 | 1500 | ||||
Max.Rotating speed (r/min) | 1100 | 1000 | 950 | 850 | 800 | ||||
Centrifuge force | 677 | 700 | 700 | 647 | 645 | ||||
Motor (kw) | 15 | 22 | 30 | 37 | 55 | ||||
Dimension (LxWxH) (mm) | 2210*1530*2200 | 2550*1800*2550 | 3020*2100*2720 | 3200*2400*3000 | 3500*2500*3300 | ||||
Weight (kg) | 3500 | 5000 | 9000 | 12000 | 17000 | ||||
Product service
2. Supply reference process flow chart .
3. Supply on-site installation and operation test
4. Integration for control system and process
5. Customized size and structure
6. 12 Months guarantee period from machine arriving date.
7. Sufficient spare parts in stock are available .
8. Technicians are available for overseas service.
9. 24 hours technical consultation.
10. The customer could get trained by our experienced technician.
FAQ
A:1) More than 50 years experience of centrifuge & separator production and R&D.We have the most professional techniques and team.More advantage in price
2)Great production capacity Sustainable Supply . According to customer requirements, We support the customized include package.
3)We use famous good quality materials and the best production process
Q2.What's the Payment?
A:T/T would be better with quick transfer and few bank fees. LC could also be accept, but the
procedure is complex and the fee is high. You can also use Western Union and Paypal.
Q3.Are you a factory or trading company?
A:We are a professional manufacturer. We are warmly welcome clients from worldwide to visit our factory and cooperate with us.
Q4.How long is the warranty period ?
A:12 months.
