Shenzhou - automatic palletizer machine for bags robot palletizer machine Filling&Packing Machine
By accurately grasping the pain points of customers, the automatic palletizer machine for bags robot palletizer machine developed by us has been supported and praised by the majority of customers in the market.The fields of application include Packaging Line.
5.0
Customization:
Customized logo (Min. Order: 1 Units),Customized packaging (Min. Order: 1 Units),Graphic customization (Min. Order: 1 Units)
shipping:
Support Sea freight · Land freight
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Our months of efforts in product R&D has finally paid off. Shenzhou Group Co.,Ltd/Liaoyang Shenzhou Machinery Equipment Co.,Ltd has successfully transformed the innovative idea into a reality - automatic palletizer machine for bags robot palletizer machine. It is the newest product series of our company now. The product is widely used to tackle the problems arising in the field(s) of Packaging Line. In the future, Shenzhou Group Co.,Ltd/Liaoyang Shenzhou Machinery Equipment Co.,Ltd will make full use of the wisdom of our talents and update our technologies to keep up with the trends, to make our dream of being a world-famous company come true.
| Type: | Packaging Line | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company |
| Showroom Location: | None | Condition: | New |
| Application: | Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware, APPAREL, Textiles, Cigarettes, Tobacco | Packaging Type: | Cartons, CANS, Bottles, Barrel, Stand-up Pouch, Bags, Film, Foil, Belt, Pouch, Capsule, case |
| Packaging Material: | Plastic, Paper, Metal, Glass, Wood | Automatic Grade: | Automatic |
| Driven Type: | Hydraulic | Voltage: | 220v |
| Place of Origin: | China | Brand Name: | LYSZ |
| Dimension(L*W*H): | 2300mmx1140mmx1800mm | Weight: | 1200 KG |
| Warranty: | 2 years | Key Selling Points: | Easy to Operate |
| Marketing Type: | New Product 2021 | Machinery Test Report: | Provided |
| Video outgoing-inspection: | Provided | Warranty of core components: | 1 Year |
| Core Components: | Other |
Product Description
The equipment is a new type of machine developed by our company in combination with advanced technology at home and abroad.Thus, the performance and working efficiency of the equipment have been greatly improved, and the requirements of fast packing have been realized. Moreover, the equipment still maintains a stable and reliable state during fast operation. This machine is suitable for automatic feeding and packing of similar bag-like items.The whole process of online material detection, manual folding (1-4 times folding) and transmission, carton absorption forming and transmission, material entering the carton, stamping batch number, paper tongue packaging at both ends of the carton (also applicable to hot melt adhesive), missing material elimination and finished product output are all completed automatically
Features：
a.Electric appliances, including the PLC, the touch screen and the frequency convertors are from well-known international brands.
b.There is the HMI.
c.Errors, working speed and the final-product counting can be automatically displayed.
d.When the box’s feeding position is not correct, or there is no box, or there is no leaflet’s feeding, the machine will be
stopped automatically.
e.When there is no content, there is no leaflet’s taking. When there is no leaflet feeding, there will be no cartonning.
f.There is the protecting if it’s overloaded.
g.Stable properties & convenient operation.
a.Electric appliances, including the PLC, the touch screen and the frequency convertors are from well-known international brands.
b.There is the HMI.
c.Errors, working speed and the final-product counting can be automatically displayed.
d.When the box’s feeding position is not correct, or there is no box, or there is no leaflet’s feeding, the machine will be
stopped automatically.
e.When there is no content, there is no leaflet’s taking. When there is no leaflet feeding, there will be no cartonning.
f.There is the protecting if it’s overloaded.
g.Stable properties & convenient operation.
model | SINOJDZ-120G( vertical) | ||||
Packing speed | 30-120box/min | ||||
Box | Quality | 250-350g/m2 (It’s decided by the box size.) | |||
Size, L×W×H | (65-155) × (30-85) × (15-50), mm | ||||
Leaflet | Quality | 60-70g/m2 | |||
Size when it’s unfolded, L×W | (80-250) × (90-170), mm | ||||
Folding | 1-4folds | ||||
Compressed air | Working pressure | Not less than 0.6Mpa | |||
Consumption | About 120 ~ 160L/min | ||||
Power supply | 220V, 50Hz | ||||
Main power | 0.75kw | ||||
Overall dimension, L×W×H | 2300× 1140 × 1800, mm | ||||
Net weight | About 1200Kg | ||||
Detailed Images.
Working principle:
Related Products.
Packing & Delivery
wooden case
Company Profile
Liaoyang Shenzhou Machinery Equipment Co., Ltd is a professional for supplier of pharmaceutical and chemical machine in China.We have a well-experienced team and a professional design institute,With rich experiences in pharmaceutical machinery and equipment including packing machine, centrifuge, falling film evaporator, distillation,mixer, tablet press machine, suppository production line,dryer,capsule filling machine ,capsule and so on.Our products are exported to many countries and areas, such as the USA, Korea, India, Indonesia,Thailand, Vietnam,Japan, Denmark,Romania, Bulgaria,Russia,South Africa, and so onAt the same time,our product with best prices and good quality,welcome to Shenzhou!
