Shenzhou - Solid State Fermenter Stainless Steel Fermenter Microbial Fermenter 380 Kg Fermentation & Mixing machine
Solid State Fermenter Stainless Steel Fermenter Microbial Fermenter 380 Kg is perfected by the adoption of high-end technology.The design of it caters to varied needs of customers at home and abroad.And the product have received the qualification.So the users can apply it into a wider range.Our products also can be customized to satisfy customers' exact requirements.
5.0
Customization:
Customized logo (Min. Order: 1 Units),Customized packaging (Min. Order: 1 Units),Graphic customization (Min. Order: 1 Units)
shipping:
Support Sea freight · Land freight
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Shenzhou Group Co.,Ltd/Liaoyang Shenzhou Machinery Equipment Co.,Ltd keeps introducing technology to manufacture Solid State Fermenter Stainless Steel Fermenter Microbial Fermenter 380 Kg. Fermenting Equipment has passed a series of international quality assurance system and product safety certification . The design is the most striking aspect of Shenzhou. Its design comes from our designers who are sensitive to fashion and are know the commercial needs of the market very well. Also, Decanter centrifuge,Disc Centrifuge,Tubular Centrifuge,Plate Centrifuge made of well-selected raw materials.
| Processing: | Fermenting Equipment | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company |
| Showroom Location: | None | Condition: | New |
| Place of Origin: | China | Brand Name: | LYSZ |
| Processing Types: | Alcohol | Voltage: | 110v,220v, 380v, adjustable |
| Power: | adjustable according to volume | Dimension(L*W*H): | customized |
| Weight: | 380 KG | Warranty: | 1 Year |
| Machinery Capacity: | 50L, 100L, 200L | Machinery Test Report: | Provided |
| Warranty of core components: | 1 Year | Core Components: | Motor |
| Key Selling Points: | Easy to Operate | Marketing Type: | New Product 2022 |
| Video outgoing-inspection: | Provided |
Product Description
Solid state fermenter Stainless steel fermenter Microbial Fermenter
Based on the research of European fermenters, the automatic control of the sterilization process of fermenters is realized through simple pipelines and heat exchange systems, which reduces the labor intensity of experimenters, has simple structure and stable operation.
Diameter to height ratio: 1:2-3; filling factor: 70%
500 liter tank: the main material is all stainless steel 316L tank, there is no dead corner in the tank; with special sampling and discharge valve for fermentation tank, and transplanting pipeline. Adopt a large-view tank liquid level observation mirror, 12V safety light, with temperature, PH, DO, defoaming, liquid level interface, inoculation port, refilling port, and multiple spare ports, all welds are firm, neat and beautiful .
Tank body: design pressure 0.3Mpa Jacket: design pressure 0.3Mpa, using optimized diversion design to improve exchange efficiency and temperature uniformity in the tank
Tank function: John Crane mechanical seal, air inlet sterilization filter, exhaust condenser, air inlet system with air distributor, flame inoculation port (also feeding port and cleaning port), discharge port, sampling port, Feeding port; the five electrodes that automatically control parameters are: PH electrode, DO electrode, defoaming electrode, and temperature electrode port; four peristaltic pumps are automatically controlled to replenish acid/alkali/foam/culture agent respectively;
Motor: SEW AC motor dedicated to fermentation tanks to ensure that the motor can run in harsh environments;
Ventilation: Adopt one way of deep ventilation, the rotor flowmeter displays, adjust the gas flow according to the process requirements, the air distributor in the tank evenly distributes the gas; adopts a sterilization filter (Dominica or Shanghai Yiming) with a precision of 0.2μm, with anti-bacterial Material backflow device to ensure safety and greatly extend the service life;
Mixing system: mechanical mixing system, SEW AC motor, Fuji inverter
Mixing form: straight blade agitating paddle (secondary), oblique blade agitating paddle (first class), mechanically compressed defoaming paddle (first class), four baffle plates;
Fermentation pH control function: using intelligent PID control, dedicated Swiss Mettler PH electrode;
Fermentation dissolved oxygen degree control function: using intelligent PID control, dedicated Swiss Mettler DO electrode;
Temperature control: electric heating, water cooling, circulating pump temperature control, air escape function and water cut, over-temperature protection function, with good heat exchange efficiency; intelligent module control not only ensures the rapidity of temperature control, but also realizes energy saving .
Feeding: a complete feeding system (acid, alkali, foaming enemy, culture agent), which can be fed regularly and quantitatively; the four peristaltic pumps can be set separately on the control interface, which is convenient and flexible in actual use. Equipped with specially designed replenishment pins to ensure the safe operation of replenishment;
Pressure detection: Swiss transmitter automatically detects the tank pressure, and the pressure is automatically released
Tank cover automatic lifting system (optional): BLBIO-UIP500 automatic tank cover lifting system through the electric system to lift the tank cover to facilitate cleaning and maintenance of the equipment in the tank
Sterilization method: BLBIO-SIP automatic program sterilization (leading technology, stable quality, low failure rate, reducing the labor intensity of the operator)
Temperature: cooling water temperature +5℃~80℃±0.2℃ tap water or ice water cooling, external circulation heating, avoid local overheating, and stable temperature control.
pH: 2.00~12.00±0.05 Two-way switch control of two peristaltic pumps
DO: 0~100%±3%
Stirring: 50~1000rpm±10% stepless speed regulation, shaft coupling drive mechanical stirring or magnetic drive mechanical stirring
Feeding: peristaltic pump duty cycle switch control
Defoaming: Sensitivity 100~100000Ω electrode detection, peristaltic pump duty cycle switch control, adding defoaming agent
Pressure: automatic pressure detection
BLBIO-S type control system is optional: Siemens S7-200 series PLC control system, mature, stable and general-purpose PLC, can be suitable for various applications of automation, especially the application in manufacturing process control. Its modularity, easy to realize distributed configuration and easy to master features, Siemens PLC control core has become an economical and advanced control system in the implementation of biological reaction process control. The system uses a tablet computer above 10 inches to control 7 direct parameters such as pH, DO, tank pressure, temperature, speed, defoaming, and refilling, and the automatic sterilization process of the tank pipeline
The pH and DO electrodes can be easily calibrated through the software; the initial control state of the parameters can be set
Specification
item | value |
Processing | Fermenting Equipment |
Applicable Industries | Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company |
Showroom Location | None |
Condition | New |
Place of Origin | China |
Brand Name | LYSZ |
Processing Types | Alcohol |
Voltage | 110v,220v, 380v, adjustable |
Power | adjustable according to volume |
Dimension(L*W*H) | customized |
Weight | 380adjustable |
Warranty | 1 Year |
Machinery Capacity | 50L, 100L, 200L |
Machinery Test Report | Provided |
Warranty of core components | 1 Year |
Core Components | Motor |
Key Selling Points | Easy to Operate |
Marketing Type | New Product 2020 |
Video outgoing-inspection | Provided |
Add optional functions:
b Weighing with replenishing balance W Tank weighing d Air flow automatic control e Tank pressure detection f Bypass pure oxygen g Redox potential online detection h Methyl (ethyl) alcohol content online detection and control I Tail gas O2, CO2 content online detection A Automatic sterilization function C Automatic tank cleaning function U Automatic lid lifting function
Model comment: BLBIO- XABC-D
X-total tank volume:
A-tank material: -G: glass/-S: stainless steel -C animal cell tank -V vaccine tank -M enzyme reactor
B—Transmission mode: -C: Magnetic drive mechanical stirring/-J direct drive mechanical stirring/ -Q airflow stirring -S solid stirring -G provide light source
C --Add optional features -A automatic sterilization -no manual sterilization -Y glass in-situ manual sterilization -U automatic lid lifting
D-Controller model-A is industrial control computer + control module-Wuwei B type controller is our company's standard controller-C is 10 inch LCD touch screen + PLC-D is 15 inch LCD touch screen + Siemens PLC + imported transmitter Device
Details
50L300L automatic sterilization fermentation tank (automatic lifting system with tank cover)
200L2000L automatic fermentation tank
50L200L3000L automatic fermentation tank
500L5000L automatic fermentation tank
Packing & Delivery
wooden case
Company Profile
Liaoyang Shenzhou Machinery Equipment Co., Ltd is a professional for supplier of pharmaceutical and chemical machine in China.We have a well-experienced team and a professional design institute,With rich experiences in pharmaceutical machinery and equipment including packing machine, centrifuge, falling film evaporator, distillation,mixer, tablet press machine, suppository production line,dryer,capsule filling machine ,capsule and so on.Our products are exported to many countries and areas, such as the USA, Korea, India, Indonesia,Thailand, Vietnam,Japan, Denmark,Romania, Bulgaria,Russia,South Africa, and so onAt the same time,our product with best prices and good quality,welcome to Shenzhou!
FAQ
1. who are we?
We are based in Liaoning, China, start from 2018,sell to North America(30.00%),South America(10.00%),Southeast Asia(10.00%),South Asia(7.00%),Eastern Europe(5.00%),Oceania(5.00%),Mid East(5.00%),Eastern Asia(5.00%),Western Europe(5.00%),Central America(5.00%),Northern Europe(5.00%),Southern Europe(5.00%),Africa(3.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Separator,Centrifuge,Packing & Filling,Drying,Tabling Machine
4. why should you buy from us not from other suppliers?
We have a well-experienced team to manufacture pharmaceutical machinery and equipment and a professional design institute. With rich experience in pharmaceutical machinery and equipment field and numbers of professional engineers.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,CPT,DDP,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,JPY,AUD,HKD,CNY,CHF;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Italian
We are based in Liaoning, China, start from 2018,sell to North America(30.00%),South America(10.00%),Southeast Asia(10.00%),South Asia(7.00%),Eastern Europe(5.00%),Oceania(5.00%),Mid East(5.00%),Eastern Asia(5.00%),Western Europe(5.00%),Central America(5.00%),Northern Europe(5.00%),Southern Europe(5.00%),Africa(3.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Separator,Centrifuge,Packing & Filling,Drying,Tabling Machine
4. why should you buy from us not from other suppliers?
We have a well-experienced team to manufacture pharmaceutical machinery and equipment and a professional design institute. With rich experience in pharmaceutical machinery and equipment field and numbers of professional engineers.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,CPT,DDP,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,JPY,AUD,HKD,CNY,CHF;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Italian
