Shenzhou Group Co.,Ltd/Liaoyang Shenzhou Machinery Equipment Co.,Ltd is reckoned for manufacturing and supplying Computerized Jacquard Needle Loom Machine that is manufactured using supreme quality materials. Computerized Jacquard Needle Loom Machine enables the company to have more market share, stronger competitiveness and higher visibility. Shenzhou Group Co.,Ltd/Liaoyang Shenzhou Machinery Equipment Co.,Ltd will strive toward excellence by building our working principles of guaranteeing quality for survival and seeking innovation for development, into everything we deliver. We are confident that we will overcome all the difficulties and obstacles to make a success in the end.
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company | Showroom Location: | None |
| Video outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2021 | Warranty of core components: | 1 Year |
| Core Components: | Engine | Condition: | New |
| Type: | Shuttle Loom | Production Capacity: | 99.9% |
| Place of Origin: | China | Brand Name: | LYSZ |
| Dimension(L*W*H): | 2800x1600x1200mm | Weight: | 3.1 KG |
| Power: | 2.5 | Warranty: | 1 Year |
| Key Selling Points: | Easy to Operate |
Model | TD736 |
Reed width (cm) | 180(74") 200(78") 230(90") 250(98") 280(110") 330(130") |
Rotation Speed(RPM) | 190-300 |
Yarn Range | Cotton:6Ne-80Ne,Wool:10Ne-135Nm,Chemical Fabric:900D-70D |
Shedding | Upper Mechanical(electronic)dobby,spring reversing motion, 20 or 24 shafts |
Weft Insertion Form | Six Linkages Weft Insertion |
Beating-up Motion | Four Linkages Short Crank Arm Beating-Up |
Take-up and Rolling-up | Continous take-up and separate rolling-up,full rolling diameter 400mm |
Weft Selection | 4-6 colors |
Diameter of Warp Beam | 600mm |
Warp Stop | 6 rows electric warp stop |
Weft Stop | Piezoelectric Ceramic Sensor Control Weft Stop |
Electric System | PLC |
Power | 1.8-2.2KW |
Weight | 3200-3500KG |
Overall Size | 3700x2000x1800(200cm/78'') |
