Shenzhou - Decanters for Used Oil Recycling Process Centrifuge & Separator

SZ SEPARATION Decanters for Used Oil Recycling Process
SZ waste oil recycling centrifuge is solid-liquid separation equipment specially developed to process and recycle industrial waste oil, motor oil, and used cooking oil. SZ decanter has continuous two-phase and three-phase separation and strong processing capacity, which can recover about 80-90% of oil (related to oil density, demulsification effect, temperature, etc.), and the slag phase after centrifuge separation. The degree can reach 40-60%, and the total volume is reduced by more than 80% compared to before separation. It can efficiently separate the light phase (oil phase) and heavy phase (water and sludge).

SHENZHOU – Our System Technology for Your Success!
From the first consulting meeting to the commissioning and maintenance of your tailor-made systems – we are at your side with support throughout the process. We always have our eye on your success.
Our employees do what it takes to develop the perfect overall concept for the machine. Tailored to your process for the efficient dewatering of paint sludge.
Use our contact form and get the advice of our decanter experts today!

2-phase separation
The 2-phase Shenzhou decanter centrifuge is designed for liquid-solids separation. Separation takes place over the entire length of the cylindrical part of the bowl, which is equipped with a concentric screw conveyor. The product is fed into the bowl through a inlet tube and is smoothly accelerated in the conveyor. Centrifugal forces cause instant sedimentation of the solids on the wall of the bowl. The clarified liquid leaves the bowl by flowing naturally under gravity, over an adjustable weir (overflow dam) and into the casing. Pressurized liquid discharge (using a centripetal pump) is also available, making it possible to transfer the liquid directly without any ambient contact and foam free. The conveyor rotates in the same direction inside the bowl but at a slightly different speed. This difference between bowl and conveyor can be adjusted either manually or automatically. This difference in speed moves the solids to the conical end, where they are lifted out of the liquid. The solids are drained before being discharged out of the machine through the solids outlet.

3-phase separation
The 3-phase Shenzhou decanter centrifuge is designed for separating raw material into three phases – light liquid, heavy liquid, and solids. The raw material is fed into the bowl through a inlet tube and is then smoothly accelerated. Separation takes place in a horizontal cylindrical bowl equipped with a screw conveyor. Centrifugal force causes instant sedimentation of the solids on the wall of the bowl. The conveyor rotates in the same direction as the bowl, but at a different speed, and conveys the solids to the conical end.
Because it is lighter, the light liquid flows on the inside, and the solids move towards the outer perimeter, while the heavy
liquid remains in the middle. Separation takes place along the entire length of the cylindrical part of the bowl. The two liquid phases discharged into collecting tanks by gravity, or under pressure by centripetal pump.

1. who are we?
We are based in Liaoning, China, start from 2018,sell to South America(12.00%),Southeast Asia(10.00%),Northern Europe(10.00%),Southern Europe(10.00%),Domestic Market(10.00%),South Asia(8.00%),Central America(6.00%),North America(5.00%),Eastern Europe(5.00%),Africa(5.00%),Oceania(5.00%),Eastern Asia(5.00%),Western Europe(5.00%),Mid East(4.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Centrifuge,Separator,Packing machine,Drying machine,Filling & Sealing machine

4. why should you buy from us not from other suppliers?
We have a well-experienced team to manufacture pharmaceutical machinery and equipment and a professional design institute. With rich experience in pharmaceutical machinery and equipment field and numbers of professional engineers.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,CPT,DDP,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,JPY,AUD,HKD,CNY,CHF;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Italian
