Titanium Decanter Centrifuge Separator Model Lw400 for Calcium Hypochlorite
Titanium Decanter Centrifuge separator Model LW400 For Calcium Hypochlorite
Titanium has good stability in acidic, alkaline, neutral salt aqueous solution and oxidizing media, better than the existing stainless steel and other non-ferrous metals corrosion resistance. Titanium good corrosion resistance and stability, determine the application of titanium in the industry is very wide.
Our equipment with large processing capacity, low energy consumption, stable performance and good separation effect,it can continuously feed, wash, dehydrate and discharge the suspension at full speed. The machine is widely used in chemical, food, salt, mining, pharmaceutical and other industries.
Practical data from our user
1) Material processed is calcium hypochlorite slurry. Also it content calcium chloride and calcium hydroxide.
2) Component content in material is calcium hypochlorite , calcium chloride , calcium hydroxide , sodium chloride
3) Slurry concentration is about 20 to 30 % solids in mixture.
4) After separation , liquid % in solid is between about 20 to 38 %.
5) Solid particle size is about 30 mesh size
6) Capacity is about 10 m3 / hr for feeding slurry separation
Technical parameter
Model | Diameter(mm) | Lenght(mm) | Max speed | L/D ratio | G-force | Capacity(m3/h) | Main motor power(Kw) | Weight(kg) | Dimension(mm) |
LW250*1000 | 250 | 1000 | 5000 | 4 | 2722 | 0.5-5 | 7.5 | 950 | 2120*1250*680 |
LW300*900 | 300 | 900 | 4200 | 3 | 2964 | 1-6 | 11 | 1160 | 2150*1300*900 |
LW300*1200 | 300 | 1200 | 4000 | 4 | 2784 | 2-6 | 11 | 1350 | 2450*1300*900 |
LW355*1160 | 355 | 1160 | 3600 | 3.3 | 2576 | 2-8 | 15 | 1400 | 2470*1350*830 |
LW355*1460 | 355 | 1460 | 3600 | 4 | 2576 | 2-10 | 15 | 1800 | 2750*1350*830 |
LW400*1200 | 400 | 1200 | 3200 | 3 | 2294 | 3-12 | 18.5 | 1800 | 2730*1600*1080 |
LW400*1600 | 400 | 1600 | 3000 | 4 | 2016 | 3-15 | 22 | 2000 | 3130*1600*1080 |
LW450*1800 | 450 | 1800 | 2800 | 4 | 1976 | 4-25 | 37 | 2500 | 3320*1700*1130 |
LW500*2000 | 500 | 2000 | 2800 | 4 | 1750 | 5-35 | 45 | 4000 | 3520*1800*1170 |
LW530*1855 | 530 | 1855 | 2600 | 3.5 | 2006 | 5-38 | 55 | 4680 | 3885*1350*1600 |
LW530*2120 | 530 | 2120 | 2400 | 4 | 1709 | 5-40 | 55 | 4800 | 4150*1350*1600 |
LW550*2000 | 550 | 2200 | 2800 | 4 | 2414 | 6-40 | 55 | 5700 | 4570*1380*1600 |
LW650*1950 | 650 | 1950 | 2200 | 3 | 1761 | 6-45 | 75 | 5000 | 4840*1510*1720 |
LW650*2600 | 650 | 2600 | 2000 | 4 | 1456 | 6-65 | 90 | 6000 | 5490-1510*1720 |
LW720*2160 | 720 | 2160 | 2000 | 3 | 1612 | 7-80 | 120 | 6000 | 5200*1600*1800 |
LW720*2880 | 720 | 2880 | 2000 | 4 | 1306 | 7-90 | 120 | 8000 | 3100*1600*1800 |
LW800*2400 | 800 | 2400 | 1800 | 3 | 1451 | 20-100 | 150 | 12000 | 5820*2000*1300 |
LW800*3200 | 800 | 3200 | 1800 | 4 | 1451 | 20-120 | 150 | 13000 | 7100*2000*1300 |
The quality factors such as crystal particle integrity, color, water content and chlorine content control of the products separated by decanter centrifuge machine all meet the production requirements.
The drum and the spiral feeder rotate in the same direction but with a certain speed difference; the material is led into the feeding spiral inner cylinder via the feeding pipe and, after speeding pipe and, after speeding up, enters the drum; under the action of the centrifugal force field, the relatively heavier solid-phase material deposits on the drum wall forming the residue layer; the solid-phase residue is continuously pushed by the spiral feeder to the conic end of the drum and, after dehydration in the drying area, is discharged out of the machine. The machine is capable of continuous feeding, separating, dehydrating and discharging under full-speed running.
A. Chemical industry Titanium anode and titanium wet chlorine gas cooler are used in chlor-alkali industry. Titanium is an excellent anticorrosive material in chemical industry and has been used more and more widely. | E. Desalination and shipbuilding Titanium is highly resistant to the corrosion of seawater and Marine air,therefore, in seawater treatment, titanium horizontal snail will also be used for wastewater treatment. |
Titanium is an excellent structural material in petroleum refining and petrochemical industry. Titanium has very good stability in organic compounds. |
Titanium has good stability in many corrosive hot water containing chlorine compounds, sulfide and so on |
Titanium is an important alloy additive in steelmaking, aluminum smelting and other industries. Titanium in the hydrometallurgical industry, titanium is an active metal, has good suction performance. |
Titanium has special corrosion resistance to chlorine dioxide, chlorite, chlorite and other bleaching agents. |
D.Fertilizer industry Urea is a very important chemical fertilizer, in the production process in high temperature and high pressure conditions corrosion is very strong, the use of titanium instead of stainless steel equipment life greatly increased, so the main equipment in urea production are using titanium. |
Titanium has good biological affinity and is harmless to human body. Therefore, it can be widely used in medical and pharmaceutical industries and other sectors.Titanium has good suction performance and is widely used in electronic vacuum technology and high vacuum technology. |
