Product Description

Large Capacity Automatic Horizontal Dewatering Centrifuge

1.brief introduction of centrifuge
This type of bag hoist discharge centrifuge are filter equipment with hermetic closure procedure task, intermittent operation and hanging bag off-site discharge.
02.working principle of centrifuge
The material is fed into the drum from the top; under the action of the centrifugal force filed, the liquid-phase passes through the filter medium and is discharged out of the machine, while the solid-phase material is retained inside the drum; after the machine is stopped, the liquid-block plate together with the filter bag is hoisted with the sling out of the machine and transferred to the designated discharge site.

Specification

	Model	PD800	PD1000	PD1250	PD1500
Bowl	Inner diameter/mm	800	1000	1250	1500
		Effective height/mm	400	500	600	745
		Filtration area/㎡	1	1.57	2.36	3.53
		Effective volume/L	100	155	420	600
		Max. loading /Kg	135	200	530	800
		Rotating speed r/min	1200	1080	950	850
		Max. Separating facto	644	644	630	605
Motor power/Kw			7.5	11	18.5	22
Dimension(L×W×H)/mm			1650×1200×1220	2000×1500×1400	2400×1800×1520	2650×2100×1820
Weight /Kg			1500	2600	4000	6400

Details Images

The motor of lifting bag centrifuge

The motor connection of lifting bag centrifuge is external. We can provide standard normal motor or explosion-proof motor. Normal
power supply is 380V 50Hz 3-phase. Different in different country can be customized.

The bowl of lifting bag centrifuge

The bowl is the main part of lifting bag centrifuge.Same as normal filter centrifuge, there are many holes,and the liquid will
flow out from the holes, then discharge from the bottom of centrifuge.All stainless steel material or better meterial.

The filter bag of lifting bag centrifuge

Lifting bag centrifuge is the same as normal filter centrifugeneed to use filter bag to save the solid. About the material, four
kinds of material can be choosen. And also the mesh number can be customized.

The lifting device of centrifuge

This is the most important part of lifting bag centrifuge,for big capacity industrial centrifuge machine, the separated solid is so heavy,worker cannot discharge manually easily. The filter bag can be discharged and lifted mechanically.

Performance characteristics

The lifting bag centrifuge is start with frequency converter for stepless speed regulation,with a PLC (programmable logic
controller) to start the steady expansion of the scope that can be used, with the main control cabinet and field proof auxiliary control panel can operate both to improve safety sex,no basis for the installation, eliminating the conventional hanging machine feet, simplify the installation process. No base plate weight and the selection of isolating types of damping system that allows devices to be completely absorbing vibrations generated by change.
On the basis of the ground and the surrounding non-interference.Shell structure for the flip,can be laminated on the centrifuge drum shell with space for thorough cleansing.Structural design is reasonable,more comprehensive cleaning and sterilization. Particularly difficult to adapt materials for the staff contact for high cleanliness,washing demanding proof high grade solid-liquid separation.Lifting bag discharge,can be off-site discharge,improve efficiency,reduce labor intensity,environmental conditions fully comply with GMP standards.

Applications:

This type filter centrifuge applies to both solid phase for the granular filtering, it can be used for dewatering fibrous
material, particularly high viscosity, fine particle size, toxic and hazardous, flammable materials in the filter. For
example:gypsum, thiamine, glauber's salt, copper sulfate, nickel sulfate, a chloride, oil, acetic acid, borax, soda, rubber
additives, dye,plastic raw materials, fertilizer, all kinds of resin, salt, MSG, food additives, starch sugar, vitamins,
antibiotics and other drugs, herbicides, insect repellents, copper, zinc, aluminum ore dehydration,metal refining,water
treatment, volleyball acid plaster.
